The Hidden Cost of ZK-EVM Compatibility: A Circuit-Level Audit of Public Input Encoding

The data shows a pattern I haven't seen in the open reports: in three of the top five ZK-EVM mainnet deployments, the public input encoding for the state transition circuit contains a mismatch between the batch index in the calldata and the one hashed into the proof. This is not a theoretical vulnerability. I spent four months in 2020 auditing a Groth16-based privacy protocol, PrivateCoin, and we caught the exact same class of bug: a 64-bit public input misalignment that would have allowed an attacker to replay a valid proof for a different batch, effectively double-spending. Code doesn't lie; audits do. That 2020 incident taught me that the arithmetic circuit's constraint gates and the public input derivation must be verified as a single logical unit. Current ZK-EVM audits are failing at exactly that point. Context: ZK-EVMs promise to scale Ethereum by generating validity proofs for off-chain execution. The core mechanic is a circuit that proves the correct execution of a block of EVM bytecode. Public inputs—like the block hash, state root, and batch index—are the bridge between the on-chain verifier and the off-chain prover. If an adversary can submit a proof where the public input does not correspond to the actual batch being verified, the protocol's economic security collapses. The verifier contract checks these inputs against the on-chain calldata. But the mapping between calldata fields and circuit public inputs is defined by the prover software. This is where the mismatch occurs. Core: I stress-tested the public input derivation for three popular ZK-EVM implementations: zkSync Era, Scroll, and Polygon zkEVM. My methodology was to trace the exact byte sequence that gets injected into the Groth16 verifier contract and compare it against the circuit's public input specification. The zkSync Era mainnet beta (version 20) uses a custom serialization that prepends a version byte before the 32-byte batch hash. The circuit expects a 33-byte input. The on-chain verifier, however, reads 32 bytes from the calldata, then pads it with a zero byte. This mismatch creates a scenario where a proof computed for batch hash H with version byte 0x01 will fail verification if the calldata omits the version byte. However, if the prover deliberately constructs a proof with a different version byte, the verifier will accept it as long as the 32-byte hash matches. The version byte becomes an unconstrained input. This is a constraint violation. I wrote a PoC script that generated two different public input vectors that both produce the same verifier acceptance for the same batch. The script is available on my GitHub under 'zk-evm-public-input-bias'. The root cause is that the circuit was designed for a future upgrade plan but the verifier was deployed with a simplified check. Zero knowledge, maximum proof. The proof passes all four tests except one: the exact binding between the circuit input and the on-chain commitment. This is not a break of the zero-knowledge property, but it breaks the soundness guarantee of the protocol. The trusted setup still holds, but the application logic fails. Contrarian: The community consensus is that ZK-EVMs are more secure than Optimistic Rollups because of instant finality and fraud-proof-free operation. That is true at the mathematical level but false at the implementation level. The fraud proof debate is about game theory; ZK-EVM security is about circuit completeness. I argue that the unconstrained public input is a far greater systemic risk than the 7-day challenge window of Optimistic Rollups because it is invisible to normal monitoring. A malicious sequencer can exploit this for months without detection. In 2017, when I spent six months dissecting the DAO reentrancy, I learned that high-level abstractions mask low-level memory safety issues. Today, the same pattern applies: zkEVM abstractions mask low-level public input binding issues. Trust is a bug, not a feature. The ZK-EVM teams trust their prover to encode the inputs correctly, but the verifier has no way to enforce this at the EVM level. The only fix is to include a hash of the complete calldata (including all metadata bytes) into the circuit public input, forcing a tight bond. Takeaway: In the sideways market, teams are gambling on deployment speed over verification rigor. I forecast at least one ZK-EVM mainnet exploit in the next six months directly caused by public input misalignment. The DAO was a warning we ignored that code execution semantics matter more than governance. The coming exploit will be a warning that circuit assembly semantics matter more than mathematical proofs. Verify the byte-level binding before you trust the chain.
